Pelco MPX2CABLARM101 Pre-Assembled Multipolar Cable (Armoured, 10 m)
The Pelco MPX2CABLARM101 is a robust 10-meter (32.8 ft) pre-cabled multipolar cable specifically engineered for use with explosion-proof PTZ cameras in the Maximus MPX Series2. It integrates power, Ethernet, and I/O lines in a single cable bundle to simplify installation and reduce field labor. The cable is equipped with a barrier cable gland (3/4″ NPT) to provide secure sealing against dust, moisture, and gas ingress, making it suitable for hazardous and outdoor environments.
Manufactured using flame-retardant materials, this cable is also resistant to oil and ultraviolet (UV) exposure, ensuring long-term durability in demanding conditions. Available in armoured (ARM) and non-armoured versions, this model (ARM) delivers mechanical protection for installations where cable durability and safety are critical.
The MPX2CABLARM101 meets a broad range of international standards and is designed to support reliable communication and power delivery across its composite conductors.
📊 Technical Specifications
| Specification Category | Parameter | Value / Detail |
|---|---|---|
| General | Product Type | Pre-cabled multipolar cable (armoured version) Security Informed |
| Length | 10 m (32.8 ft) Security Informed+1 | |
| Cable Gland | Barrier cable gland, 3/4″ NPT Security Informed | |
| Mechanical | External Diameter (ARM) | ~20.5 mm ± 0.5 mm Security Informed |
| Diameter under Armour | ~16 mm Security Informed | |
| Minimum Bending Radius | ~184.5 mm Security Informed | |
| Electrical / Wiring | Power Conductors | 3 conductors (2.5 mm² each) Security Informed |
| I/O Conductors | 8 conductors, shielded, 0.34 mm² each Security Informed | |
| Ethernet Cable | Category 5e, 4×2×0.20 mm², SF/UTP Security Informed | |
| Environmental & Durability | Operating Temperature | –60 °C to +105 °C (ARM version) Security Informed |
| Oil Resistance | Complies with CNOMO, ASTM, IRM 902 Security Informed | |
| UV Resistance | UL 1581 / IEC / relevant UV standards Security Informed | |
| Flame / Fire Standards | IEC/EN 60332-1, IEC/EN 60332-3-22, IEC/EN 60079-14 (for explosive area) Security Informed | |
| Certifications | Explosive / Hazardous Use | ATEX / Ex/ II compliance as per Pelco & Electrical standards Security Informed |
| Other Compliance | RoHS (2015/863/EU) Security Informed |
