Description

• Features
  Gigabit Ethernet Switch
   Fanless Gigabit Ethernet Switch
   Low power consumption switchchipset, Energy-Efficient Ethernet
   Layer-2+ store-and-forward,
  full wire-speed, non-blocking
   Max. 8,192 MAC-addresses, automatic
  learning and aging
   Jumbo-Frames (max. 10,240 Bytes)
  Energy-Efficient Ethernet
   IEEE 802.3az
   Optimised power consumption for
  each RJ-45 port depending on the
  actual requirement
   Up to 50% reduced power
  consumption
  Network Management
   Support of common management
  standards
   800 MHz ARM CPU
   Linux operating system with fast
  system boot
   Web Manager (HTTPS (default)/HTTP)
   Telnet/SSH/Console, incl. standardcommands (ping, traceroute, etc.)
   SNMP v1/v2c/v3
   Central management software as
  option (MICROSENS NMP)
   IPv4/IPv6 Dual Stack
   Integrated CLI scripting to automate
  routine processes
   Firmware, script and configuration
  files can be loaded, saved and
  executed directly on the switch
   Incremental firmware updates
  possible
   Exchangeable MicroSD memory card
  for configuration, CLI scripts,
  firmware, and MAC address (optional)

DataSheet
