• Network Ports : 24x 25 Gigabit Ethernet SFP28
• Product Family : Catalyst 9500 Series
• Management Ports : 1x USB, 1x Mini USB, 1x RJ45 Console, 1x Gigabit Management
• Stacking Options : StackWise Virtual (SWV) is supported on this switch. The software is designed to connect two physical switches so they act like a single logical unit.
• Stacking Cable Options : The user can stack 2x C9500 switches together using a high speed Ethernet cable.
• Switch Version : Network Advantage
• AirFlow Direction : Front-to-Back Airflow
• Fan Module Options : 4x C9K-T1-FANTRAY Fans Modules Included
• Power Supplies Included : 1x C9K-PWR-650WAC-R Power Supply Included – 2x Slots – 2nd Power Supply ordered Separately
• Power Supply Options : C9K-PWR-650WAC-R, C9K-PWR-930WDC-R
• Jumbo Frame Support : 9198 bytes
• Switching Capacity : Up to 1.6 Tbps
• Forwarding Rate : Up to 1 Bpps
• MAC Address Table Size : 82,000
• DRAM and Flash : 4GB DDR2 SDRAM, 16GB Flash
• Model Number : C9500-24Y4C-A
• Part Number : C9500-24Y4C-A, C9500-24Y4C-A=, C9500-24Y4C-A-WS
• Condition : Seller refurbished

Datasheet
