Avigilon RM7X-WKS-2MN-EU

Product Description

The Avigilon RM7X-WKS-2MN-EU is a professional Remote Monitoring Workstation designed for video surveillance monitoring and management applications. It is optimized for use with the Avigilon Control Center (ACC) Client and provides a dedicated workstation platform for security operators who need to monitor and manage video surveillance systems across up to two monitors.

The workstation is designed specifically for professional security and surveillance environments, providing a reliable platform for displaying live camera feeds, reviewing recorded video, managing surveillance views, and operating Avigilon video management applications. Its compact Form H tower configuration allows it to be deployed conveniently at security monitoring desks, control rooms, command centers, and other professional surveillance workstations.

The RM7X-WKS-2MN-EU is the European-region configuration of the RM7X remote monitoring workstation family and includes the appropriate EU configuration and power requirements. The system supports dual-monitor operation through its DisplayPort outputs and includes DisplayPort-to-HDMI adapters for connecting compatible HDMI displays. The monitor itself is sold separately.

Key Features

• Professional Avigilon remote monitoring workstation
• Designed for surveillance and security monitoring applications
• Optimized for Avigilon Control Center Client software
• Supports up to 2 monitors
• Dual DisplayPort video outputs
• Includes 2 × DisplayPort-to-HDMI adapters
• Microsoft Windows 11 IoT Enterprise LTSC (2024)
• Intel Core processor platform
• DDR5 system memory
• M.2 PCIe NVMe solid-state storage
• Integrated Intel graphics
• 1 × Gigabit Ethernet port
• 1 × 2.5 Gigabit Ethernet port
• Compact Form H tower design
• USB keyboard and USB mouse included
• EU power configuration
• Suitable for professional security control rooms and surveillance workstations
• Designed for continuous professional video monitoring applications

Technical Specifications

Specification	Details
Brand	Avigilon
Product Family	RM7X
Model / Part Number	RM7X-WKS-2MN-EU
Product Type	Remote Monitoring Workstation
Workstation Type	Video Surveillance Client Workstation
Form Factor	Form H / Tower
Monitor Support	Up to 2 Monitors
Operating System	Microsoft Windows 11 IoT Enterprise LTSC (2024)
Processor	Intel Core i5
System Memory	16 GB DDR5 RAM
Storage	256 GB M.2 PCIe NVMe Class 35 SSD
Graphics	Intel Integrated Graphics
Display Outputs	2 × DisplayPort
Display Adapters	2 × DisplayPort-to-HDMI adapters included
Ethernet	1 × 1 GbE RJ-45 + 1 × 2.5 GbE RJ-45
Optical Drive	DVD-RW
Power Input	90–264 VAC
Power Frequency	50/60 Hz
Maximum Power Consumption	300 W
Dimensions	384 × 308 × 100 mm
Approx. Weight	6 kg
Operating Temperature	+5°C to +35°C
Keyboard	USB Keyboard Included
Mouse	USB Mouse Included
Power Cable	Included
Monitor	Sold Separately
Regional Configuration	EU
Intended Application	Professional Video Surveillance and Security Monitoring

The above configuration is reported for the current RM7X-WKS-2MN-EU listing, while the Avigilon RM7X datasheet confirms the two-monitor configuration, included USB keyboard and mouse, power cord, two DP-to-HDMI adapters, and the RM7X family ordering structure.

Display and Monitor Support

The RM7X-WKS-2MN-EU is designed to support surveillance operators working with up to two displays simultaneously. The workstation provides two DisplayPort outputs, allowing two compatible monitors to be connected directly. Two DisplayPort-to-HDMI adapters are supplied with the workstation, providing additional flexibility when connecting HDMI-based surveillance monitors.

This dual-monitor configuration is particularly useful for displaying multiple camera views, live surveillance feeds, maps, alarms, playback windows, and other elements of a video management system at the same time.

Operating System

The workstation is configured with Microsoft Windows 11 IoT Enterprise LTSC (2024), providing a professional operating environment suitable for dedicated security and surveillance applications. The system is intended to operate as a dedicated client workstation for Avigilon video management software rather than as a general-purpose office computer.

Processor and Memory

The current listed configuration uses an Intel Core i5 processor combined with 16 GB of DDR5 RAM. This configuration provides the processing and memory resources required for professional video surveillance client operations and multi-monitor monitoring applications.

Storage

The RM7X-WKS-2MN-EU includes a 256 GB M.2 PCIe NVMe Class 35 SSD. The solid-state storage provides fast system access and is intended primarily for the workstation operating system, client software, and associated system applications rather than serving as the primary long-term video recording storage platform.

Graphics

The workstation uses Intel Integrated Graphics and provides two DisplayPort outputs for its dual-monitor configuration. The included DisplayPort-to-HDMI adapters allow compatible HDMI displays to be connected to the workstation.

Network Connectivity

For network communication with surveillance systems and video management infrastructure, the workstation provides two RJ-45 Ethernet interfaces:

• 1 × 1 Gigabit Ethernet
• 1 × 2.5 Gigabit Ethernet

This network configuration provides flexible connectivity for professional surveillance environments and allows the workstation to communicate with the network infrastructure, video management systems, cameras, servers, and other security equipment as required by the system design.

Optical Drive

The listed configuration includes a DVD-RW optical drive, providing the ability to read and write compatible optical media when required for system administration, maintenance, or other supported applications.

Power Requirements

The EU version of the workstation supports an input voltage range of 90–264 VAC at 50/60 Hz. The specified power consumption is 300 W. The workstation is supplied with the appropriate power cord for its regional configuration.

Physical Specifications

The workstation measures approximately 384 × 308 × 100 mm and has a listed weight of approximately 6 kg. Its compact tower-style Form H design makes it suitable for deployment on or around professional monitoring desks and security control-room workstations.

Operating Environment

The specified operating temperature range for the RM7X-WKS-2MN-EU is +5°C to +35°C. The workstation is intended for controlled indoor environments such as security operation centers, surveillance control rooms, monitoring stations, and other professional IT or security installations.

Included Accessories

The RM7X-WKS-2MN-EU is supplied with the following accessories:

• USB keyboard
• USB mouse
• Power cord
• 2 × DisplayPort-to-HDMI adapters

Monitors are sold separately.

Applications

The Avigilon RM7X-WKS-2MN-EU is suitable for a wide range of professional security and surveillance applications, including:

• CCTV monitoring stations
• Security operation centers
• Video surveillance control rooms
• Security command centers
• Avigilon Control Center client workstations
• Multi-camera monitoring
• Live video surveillance
• Recorded video review
• Security event monitoring
• Professional video management environments
• Enterprise and commercial surveillance installations
• Critical infrastructure monitoring
• Access and security control rooms

Avigilon Video Management Integration

The workstation is designed as a dedicated client platform for the Avigilon video surveillance ecosystem. It provides the hardware and operating environment required for professional operators to interact with Avigilon client applications and monitor connected surveillance systems.

With support for two monitors, dual network interfaces, integrated graphics, and a dedicated Windows IoT operating environment, the RM7X-WKS-2MN-EU is optimized for applications where reliable video display and continuous access to surveillance information are essential.

Installation

The RM7X-WKS-2MN-EU should be installed in a suitable indoor environment with adequate ventilation and access to an appropriate AC power source. The workstation can be connected to one or two compatible monitors using its DisplayPort outputs or the supplied DisplayPort-to-HDMI adapters.

The workstation should be connected to the appropriate surveillance network using its available Ethernet interfaces. Avigilon client software and system configuration should be completed according to the applicable Avigilon documentation and the requirements of the installed video surveillance system.

Certifications and Compliance

The RM7X product family datasheet lists the following certifications and approvals:

• UL
• cUL
• CE
• UKCA
• RoHS
• RCM
• KC
• NOM
• BSMI
• CCC
• NRCS
• VCCI
• CMIM
• PSB

The listed safety and electromagnetic compatibility standards include UL/CSA/IEC/EN 62368-1, FCC Part 15 Subpart B Class B, ICES-003 Class B, EN 55032 Class B, EN 61000-3-2, EN 61000-3-3, and EN 55035.

Ordering Information

Manufacturer: Avigilon
Product Family: RM7X Remote Monitoring Workstation
Part Number: RM7X-WKS-2MN-EU
Configuration: Up to 2 Monitors
Region: EU
Form Factor: Form H
Primary Application: Professional Video Surveillance Monitoring

Product Summary

The Avigilon RM7X-WKS-2MN-EU Remote Monitoring Workstation is a dedicated professional surveillance workstation designed for applications requiring reliable operation of Avigilon video management and monitoring software. Supporting up to two monitors, the system provides a practical platform for displaying multiple surveillance views and managing live and recorded video from a centralized operator workstation.

Its configuration includes a modern Intel Core processor, 16 GB DDR5 memory, 256 GB PCIe NVMe SSD storage, integrated Intel graphics, dual DisplayPort outputs, two Ethernet interfaces with 1 GbE and 2.5 GbE connectivity, Windows 11 IoT Enterprise LTSC 2024, and a compact Form H tower chassis.

The workstation is supplied with a USB keyboard, USB mouse, power cord, and two DisplayPort-to-HDMI adapters, making it a complete client-side platform for professional surveillance installations. Monitors are not included and are sold separately.
